- Bench constructed from stainless steel frame with castor wheels.
- Fully automated and user‑friendly operation.
- Requires minimal operator intervention.
- Supports a wide range of temperature and pressure settings for polymerization experiments.
Emulsion Polymerization Reactor
PMI’s Advanced Emulsion Polymerization Reactor is designed for polymer synthesis under controlled temperature and pressure conditions.
Specifications:
| Reactor Size | 1liter double layer reactor with vacuum jacket |
| Reactor Vessel | Reactor head equipped with gas inlet and release ports fitted with appropriate valves, additional ports for instrumentation, and a polymer sample outlet. |
| Stirrer | Magnetic drive (1/4 HP) with anchor stirrer; speed range 10 to 800 rpm; interchangeable stirrer blades available. |
| Accessories | Reactor equipped with sight glass, automated pH and conductivity meters, and an argon gas supply (with cylinder) to maintain an inert atmosphere |
| Temperature | Ambient to 300 °C (minimum). |
| Pressure limit | Atmospheric pressure up to 10 bar. |
| Data storage and control | Data Storage and Control: Automated data acquisition and control via PC. |
| Electrical supply | 120 VAC or 220 VAC. |
