Custom Porometer

Custom Porometer

The characteristics of porous material are unique and often very complex. The customer desires to test his unique porous material and measure the pore structure characteristics relevant to his applications. Therefore, a custom porometer designed to meet the specific requirements of a customer is appropriate and economical.

Test Pressure up to 500 psi (up to 2,000 psi with microflow)
Pressure Accuracy 0.15 % of reading
Flow Rates Up to 200 SLPM (standard liters per minute) (up to 10,000 SLPM optional)
Flow Accuracy 1% of F.S.
Sample Size

Standard: 0.25″ – 2.5″ diameter (up to 1.5″ thick)

Standard: 5 mm – 60 mm diameter (up to 40 mm thick)

Others available
Pressure and Flow Resolution 1/60,000 of full scale (1 part in 60,000)
Compressive Stress Up to 1,000 psi
Maximum Pore Size Detectable 1,000 μm
Minimum Pores Sizes Detectable 0.013 μm (0.004 μm with microflow)
Sample Type Sheets, Rods, Tubes, Hollow Fibers, Cartridges, Powders, High Flow Samples, Nearly Impermeable Samples, and many more





Category:

The characteristics of porous material are unique and often very complex. The customer desires to test his unique porous material and measure the pore structure characteristics relevant to his applications. Therefore, a custom porometer designed to meet the specific requirements of a customer is appropriate and economical.



  • Multiple sample chambers for fast characterization of samples
  • Multiple test modes including fast QC mode and sophisticated
  • Multiple test environments including elevated temperatures, compressive stress, and chemical environments.
  • Multiple sample chamber configuration
  • Windows based software for simple operation
  • Completely automated
  • Operator involvement minimal
  • Testing time only a few minutes
